Mineral Wool Insulation Slab
Mineral Wool Insulation Slab

Mineral Wool Insulation Slab

Product ID : IK-RWB002
Product Attributes :

50mm mineral wool insulation board is a high-performance thermal insulation material made from natural basalt mineral fibers through high-temperature melting and fiber forming. It provides excellent fire resistance, thermal insulation, and acoustic performance for building and industrial applications.

With a stable, rigid structure and uniform density, the 50mm thickness is widely used in wall insulation, HVAC duct systems, roof insulation, steel structures, and industrial equipment protection. It effectively reduces heat loss, improves energy efficiency, and enhances overall fire safety in construction projects.

This product is non-combustible and can withstand high temperatures without deformation, making it a reliable insulation solution for both commercial and industrial environments.

Product Description

Stack of 50 mm mineral wool insulation boards with cut edges facing the camera

50mm Mineral Wool Insulation Board

This board is cut at 50 mm thickness from high-density mineral wool, at 60-120 kg/m3 and A1 non-combustible. The 50 mm section is the standard choice where a single layer has to fit inside a confined wall cavity, a ceiling void or a sandwich panel core, and where fire performance cannot be traded for thickness.

Why 50 mm is specified

  • Fits stud walls, rafter voids and ceiling grids without compressing services
  • A1 non-combustible, does not melt or emit toxic smoke at high temperature
  • Water repellent treatment keeps thermal performance in humid build-ups
  • Dimensional stability holds the board tight in the cavity over time

Typical applications

The 50 mm board insulates external wall cavities behind cladding, internal partition walls for acoustic separation, flat roof and terrace build-ups, and industrial enclosures where a thin fire barrier is needed. It is also used as the core layer in mineral wool sandwich panels for workshops and cold storage ante-rooms.

Supply specification

Thickness50 mm
Density60-120 kg/m3
Fire ratingA1 non-combustible
FormRigid board, cut to panel size
UseWall cavity, roof, partition, panel core

Ordering notes

Tell us the panel length and width you need, the density band for your U-value target, and whether the board will be friction fitted or fixed with pins. For multi-layer build-ups we can advise the 50 mm plus 50 mm stack that reaches your required thermal resistance.
